SECTION 2
2.2. Technical Specifications Continued
Fuse Protection
Main Control Card
Aux. Supply
Charger (Mains Supply)
Motor push force - starting
Motor push force - rated
Gate mass - maximum
Gate length - maximum
Gate speed (varies with load)
Manual Override
Operations in standby (6Ah Batteries)
Half day
5,6
Full day
5,6
Collision Sensing
Operating temperature range
Onboard receiver type
Receiver code storage capacity
Receiver frequency
Degree of protection
Mass of unit packed (with standard kit, but
excl. rack and battery)
Packaging dimensions (with standard kit,
but excl. rack and battery)
1. Can operate off a solar supply, consult your local dealer for assistance
2. Based on 25°C ambient temperature and unit not in direct sunlight
3. Based on a motor push force of less than 50% of rated (Starting and Running forces)
4. Gate opening and closing speeds can be configured to run slower depending on the requirements of individual installations
5. Can increase battery capacity for longer standby times
6. Based on 4m gate, excluding all accessories
7. Multiple buttons per remote can be used
Resetable Fuse
Non-serviceable
4
Code-hopping multichannel receiver
page 10
Type
Serviceable
(10sec Pulse)
3A slow-blow
30kgf
17kgf
500kg
100m
30m/min @ 17kgf
Lockable with key release
44
35
Electronic
-15°C to +50°C
with selective add and delete
1500 Remotes
433.92MHz
IP55
9.1kg
325mm wide x 244mm deep
x 445mm high
TABLE 1 CONTINUED
SPECIFICATIONS
Rating
25A
12V 600mA
or
24V 3A
7
