Verify a DIMM

4. Line up the replacement DIMM with the connector.
Align the DIMM notch with the key in the connector, as in panel 3. This action ensures that the
DIMM is oriented correctly. Panel 2 shows an incorrect alignment.
Push the DIMM into the connector until the ejector tabs lock the DIMM in place.
5.
If the DIMM does not easily seat into the connector, verify that the orientation of the DIMM is
correct. Never apply excessive force.
6. Return the server module to operation.
See "Returning the Server Module to Operation" on page
7. Verify the DIMM.
See "Verify a DIMM" on page
Related Information
"Remove a DIMM" on page 68
■
"DIMM FRU Names" on page 64
■
"DIMM Configuration" on page 63
■
Verify a DIMM
Access Oracle ILOM.
1.
See "Log Into Oracle ILOM (Service)" on page
2.
Set the virtual keyswitch to diag so that POST will run in Service mode.
-> set /SYS keyswitch_state=Diag
Set 'keyswitch_state' to 'Diag'
3. Reset the host so that POST runs.
-> reset /System
Are you sure you want to reset /System (y/n)? y
4. Return the virtual keyswitch to Normal mode.
-> set /SYS keyswitch_state=Normal
70 SPARC T5-1B Server Module Service Manual • February 2019
