Remove the Server Module From the Modular System

Set 'prepare_to_remove_action' to 'true'
From the server module, type.
■
-> set /SYS prepare_to_remove_action=true
Set 'prepare_to_remove_action' to 'true'
5. Confirm that the server module is in standby mode by viewing the blue Ready to
Remove LED on the front of the server module.
See "Front and Rear Panel (Service)" on page 12
LED is on, the server module is ready for removal from the modular system chassis.
Remove the server module from the chassis.
6.
See "Remove the Server Module From the Modular System" on page
Related Information
"Remove the Server Module From the Modular System" on page 48
■
"Shut Down the OS and Host (Commands)" on page 44
■
"Shut Down the OS and Host (Power Button – Graceful)" on page 45
■
"Shut Down the OS and Host (Emergency Shutdown)" on page 46
■
Remove the Server Module From the Modular System
1. Review the safety and handling precautions.
See "Safety Information" on page
Caution -
server module within 60 seconds.
Prepare the server module for removal.
2.
See "Preparing the Server Module for Removal" on page
3. If a cable is connected to the front of the server module, disconnect it.
Press the buttons on either side of the UCP to release the connector.
4. Open both ejector arms (panel 1).
48 SPARC T5-1B Server Module Service Manual • February 2019
39.
When the modular system is operating, you must fill every slot with a filler panel or a
to locate this LED. If the Ready to Remove
48.
44.
