Vme-P1; 80Pin Interboard Connector 1 Pinout (P5) - Xycom XVME-976/202 Manual

Name Pin
A1 USER I/O - 2
A2 USER I/O - 4
A3 USER I/O - 6
A4 USER I/O - 8
A5 USER I/O - 10
A6 USER I/O - 12
A7 USER I/O - 14
A8 USER I/O - 16
A9 USER I/O - 18
A10 USER I/O - 20
A11 USER I/O - 22
A12 USER I/O - 24
A13 USER I/O - 26
A14 USER I/O - 28
A15 USER I/O - 30
A16 USER I/O - 32
A17 USER I/O - 34
A18 USER I/O - 36
A19 USER I/O - 38
A20 USER I/O - 40
A21 USER I/O - 42
A22 USER I/O - 44
A23 USER I/O - 46
A24 USER I/O - 48
A25 USER I/O - 50
A26 USER I/O - 52
A27 USER I/O - 54
A28 USER I/O - 56
A29 USER I/O - 58
A30 USER I/O - 60
A31 USER I/O - 62
A32 USER I/O - 64

VME-P1

Used for +5v,+12v & -12v routing only. IACKIN* tied to IACKOUT*,
BGXIN* tied to BGXOUT*.

80pin Interboard Connector 1 Pinout (P5)

This proprietary connector has all the PCI signals along with 4 separate PCI
clocks and the 4 request and grants predefined. The CPU board and the In-
terface boards will be keyed for either 3.3V or 5V signaling. The keying
mechanism is based on standoffs. At this point all CPU boards will be 5V
PCI signaling. The V/IO pins on the connector are used to define the sig-
naling level to the other PCI boards.
Table 1-5. VME P2 Connector Pinouts
Name Pin
B1 VCC
B2 GND
B3 NC
B4 NC
B5 NC
B6 NC
B7 NC
B8 NC
B9 NC
B10 NC
B11 NC
B12 GND
B13 VCC
B14 NC
B15 NC
B16 NC
B17 NC
B18 NC
B19 NC
B20 NC
B21 NC
B22 GND
B23 NC
B24 NC
B25 NC
B26 NC
B27 NC
B28 NC
B29 NC
B30 NC
B31 GND
B32 VCC
Chapter 1 – Introduction
Name Pin
C1 USER I/O - 1
C2 USER I/O - 3
C3 USER I/O - 5
C4 USER I/O - 7
C5 USER I/O - 9
C6 USER I/O - 11
C7 USER I/O - 13
C8 USER I/O - 15
C9 USER I/O - 17
C10 USER I/O - 19
C11 USER I/O - 21
C12 USER I/O - 23
C13 USER I/O - 25
C14 USER I/O - 27
C15 USER I/O - 29
C16 USER I/O - 31
C17 USER I/O - 33
C18 USER I/O - 35
C19 USER I/O - 37
C20 USER I/O - 39
C21 USER I/O - 41
C22 USER I/O - 43
C23 USER I/O - 45
C24 USER I/O - 47
C25 USER I/O - 49
C26 USER I/O - 51
C27 USER I/O - 53
C28 USER I/O - 55
C29 USER I/O - 57
C30 USER I/O - 59
C31 USER I/O - 61
C32 USER I/O - 63
1-17
