XVME-977 Hard Disk/Floppy Disk Module

Floppy Drive Connector (P3)

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13

Hard Drive Connector (P4)

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
2-6
Signal Pin Signal
+5V 14 FSTEP*
IDX* 15 GND
+5V 16 FWD*
FDS1* 17 GND
+5V 18 FWE*
DCHG* 19 GND
NC 20 FTK0*
NC 21 GND
NC 22 FWP*
MO1* 23 GND
NC 24 FRDD*
FDIRC* 25 GND
NC 26 FHS*
Signal Pin Signal
NC 26 NC
NC 27 HDRQ
NC 28 GND
NC 29 DIOW*
NC 30 GND
NC 31 DIOR*
HDRESET* 32 GND
GND 33 IORDY
HD7 34 ALE
HD8 35 HDACK*
HD6 36 GND
HD9 37 IRQ14
HD5 38 IOCS16*
HD10 39 DA1
HD4 40 NC
HD11 41 DA0
HD3 42 DA2
HD12 43 CS1P*
HD2 44 CS3P*
HD13 45 IDEATP*
HD1 46 GND
HD14 47 +5V
HD0 48 +5V
HD15 49 GND
GND 50 NC
