Appendix
Attribute
5
7 7
6
7
8
9
Table 7.11 Instance Attributes-Class ID 0xF6 Link Object
Service code
01h
0Eh
10h
43h
Table 7.12 Services Supported
42
Access
Name
rule
Media counters
Alignment errors
FCS errors
Single collisions
Multiple collisions
SQE test errors
Deferred
transmissions
Get
Late collisions
Excessive collisions
MAC transmit
errors
Carrier sense
errors
Frame too long
MAC receive errors
Interface control
Control bits
Set
Forced interface
speed
Get Interface label SHORT_STRING
Get Link list size
Get Link list ARRAY OF uint
Supported
Class Instance
Yes Yes
Yes Yes
– Yes
– Yes
Danfoss A/S © 06/2016 All rights reserved.
EtherNet/IP
Data type Description of attribute
STRUCT of: Media-specific counters.
Frames received that are not an integral
UDINT
number of octets in length.
Frames received that do not pass the FCS
UDINT
check.
Successfully transmitted frames which
UDINT
experienced exactly 1 collision.
Successfully transmitted frames which
UDINT
experienced more than 1 collision.
Number of times SQE test error message is
UDINT
generated.
Frames for which first transmission attempt
UDINT
is delayed because the medium is busy.
Number of times a collision is detected
UDINT later than 512 bit times into the
transmission of a packet.
Frames for which transmission fails due to
UDINT
excessive collisions.
Frames for which transmission fails due to
UDINT
an internal MAC sub layer transmit error.
Times that the carrier sense condition was
UDINT lost or never asserted when attempting to
transmit a frame.
Frames received that exceed the maximum
UDINT
permitted frame size.
Frames for which reception on an interface
UDINT fails due to an internal MAC sub layer
receive error.
STRUCT of: Configuration for physical interface.
WORD Interface control bits.
Speed at which the interface shall be
Uint forced to operate speed in Mbps (10, 100,
1000, and so on).
Human readable identification.
USINT Number of members in link list.
Link list between internal and all
corresponding external interfaces.
Service name
Get_attribute_all
Get_attribute_single
Set_attribute_single
Get_and_clear
Parameter in frequency
Description of service
Returns a predefined listing of the objects attributes.
Returns the contents of the specified attribute.
Modifies a single attribute.
Gets, then clears the specified attribute (interface
counters or media counters).
converter
–
12-99 [0]
12-99 [1]
12-99 [2]
12-99 [3]
12-99 [4]
12-99 [5]
12-99 [6]
12-99 [7]
12-99 [8]
12-99 [9]
12-99 [10]
12-99 [11]
–
–
–
–
–
–
MG07H102
