Appendix
Attribute Access
13 Get Fault code
15 Get Control from net
Table 7.5 Instance Attributes-Class ID 0x29 Control Supervisor Object
CIP malfunction Meaning
code
0 No alarm
0 Unused
Frequency converter overtem-
4210
perature
2240 Ground fault
0 Unused
8100 Control word timeout
2310 Overcurrent
8302 Torque limit
4310 Motor thermistor
4310 Motor ETR overtemperature
2311 Inverter overloaded
3220 DC-link undervoltage
3210 DC-link overvoltage
2130 Short circuiting
2213 Inrush fault
3130 Mains phase loss
5210 AMT fail
1000 Live zero fault
6100 Internal fault
7110 Brake resistor power limit
3300 Motor phase U missing
3300 Motor phase V missing
3300 Motor phase W missing
8100 Fieldbus fault
5112 24 V supply fault
3100 Mains failure
5110 1.8 V supply fault
7110 Brake resist. short circ.
7110 Brake chopper fault
0 Unused
0 Unused
0 Unused
0 Unused
Table 7.6 Attribute 13 Fault Code
MG07H102
Programming Guide
Name Data type
Uint
Boolean
Frequency converter
code alarm word
0000 0000
0000 0001
0000 0002
0000 0004
0000 0008
0000 0010
0000 0020
0000 0040
0000 0080
0000 0100
0000 0200
0000 0400
0000 0800
0000 1000
0000 2000
0000 4000
0000 8000
0001 0000
0002 0000
0004 0000
0008 0000
0010 0000
0020 0000
0040 0000
0080 0000
0100 0000
0200 0000
0400 0000
0800 0000
1000 0000
2000 0000
4000 0000
8000 0000
Danfoss A/S © 06/2016 All rights reserved.
Description
Mapping of parameter 16-90 Alarm Word to CIP-
specific fault codes.
Parameter 12-31 Net Reference value written from
option.
CIP malfunction meaning
No fault
No fault
Excessive device temperature
Short to ground
No fault
Communication
Continuous overcurrent
Torque limiting
Excess frequency converter temperature
Excess frequency converter temperature
Current inside the device, No. 1
Undervoltage inside the device
Overvoltage inside the device
Short circuit
Overcurr.marduring start-up
Phase failure
Measurement circuit
General fault
Internal software fault
Brake chopper
Output voltage
Output voltage
Output voltage
Communication
+24 V power supply
Mains voltage
Low voltage power supply
Brake chopper
Brake chopper
No fault
No fault
No fault
No fault
CIP classifi-
cation
–
–
MAR
MAU
–
MIR
MAU
7 7
MAR
MAR
MAR
MAR
MAR
MAR
MAU
MAU
MIR
MAR
MAU
MAU
MAU
MAU
MAU
MIR
MAU
MAR
MAU
MAR
MAR
–
–
–
–
