Parameters
8-50 Coasting Select
Option:
[3] Logic OR
*
8-51 Quick Stop Select
Select the trigger for the quick stop function.
Option:
[0]
[1]
5 5
[2]
[3]
*
8-52 DC Brake Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR Activate a start command via the fieldbus/serial
*
8-53 Start Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-54 Reversing Select
Option:
[0] Digital
input
[1] Bus
24
EtherNet/IP
Function:
The fieldbus/serial communication port or a
digital input triggers the coasting function.
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
When parameter 1-10 Motor Construction is
set to [1] PM non-salient SPM, only
selection [0] Digital input is available.
Activate a start command via a digital input.
Activate a start command via the serial
communication port or fieldbus option.
Activate a start command via the fieldbus/serial
communication port and via 1 of the digital
inputs.
communication port or via 1 of the digital
inputs.
Function:
Select the trigger for the start function.
A digital input triggers the start function.
A serial communication port or the fieldbus
triggers the start function.
The fieldbus/serial communication port and a
digital input trigger the start function.
The fieldbus/serial communication port or a
digital input triggers the start function.
Function:
Select the trigger for the reversing function.
A digital input triggers the reversing function.
A serial communication port or the fieldbus
triggers the reversing function.
Danfoss A/S © 06/2016 All rights reserved.
8-54 Reversing Select
Option: Function:
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the reversing function.
[3] Logic OR The fieldbus/serial communication port or a
digital input triggers the reversing function.
8-55 Set-up Select
Option: Function:
Select the trigger for the set-up selection.
[0] Digital A digital input triggers the set-up selection.
input
[1] Bus A serial communication port or the fieldbus
triggers the set-up selection.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the set-up selection.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input triggers the set-up selection.
8-56 Preset Reference Select
Option: Function:
Select the trigger for the preset reference
selection.
[0] Digital A digital input triggers the preset reference
input selection.
[1] Bus A serial communication port or the fieldbus
triggers the preset reference selection.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the preset reference
selection.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input triggers the preset reference
selection.
8-57 Profidrive OFF2 Select
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-58 Profidrive OFF3 Select
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] Logic OR
*
Function:
Function:
