Parameters
12-18 Supervisor MAC
Range: Function:
0 [0 - 2147483647] Show the MAC address of currently active
*
supervisor.
12-19 Supervisor IP Addr.
Range: Function:
0 [0 - 2147483647] Show the IP Address of currently active
*
supervisor.
5.2.3 12-2* Process Data
12-20 Control Instance
Range: Function:
Size related [0 - 255] Show the originator-to-target
*
connection point. If no CIP connection
is present, none is shown.
12-21 Process Data Config Write
Option:
[0] None
*
[302] Minimum Reference
[303] Maximum Reference
[312] Catch up/slow Down Value
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[412] Motor Speed Low Limit [Hz]
[414] Motor Speed High Limit [Hz]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[553] Term. 29 High Ref./Feedb. Value
[558] Term. 33 High Ref./Feedb. Value
[590] Digital & Relay Bus Control
[593] Pulse Out 27 Bus Control
[615] Terminal 53 High Ref./Feedb. Value
[625] Terminal 54 High Ref./Feedb. Value
[696] Terminal 42 Output Bus Control
[748] PCD Feed Forward
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[3401] PCD 1 Write For Application
[3402] PCD 2 Write For Application
[3403] PCD 3 Write For Application
[3404] PCD 4 Write For Application
[3405] PCD 5 Write For Application
[3406] PCD 6 Write For Application
[3407] PCD 7 Write For Application
MG07H102
Programming Guide
12-21 Process Data Config Write
Option:
[3408]
[3409]
[3410]
12-22 Process Data Config Read
Option:
[0]
*
[2]
[413]
[1500]
[1501]
[1502]
[1600]
[1601]
[1602]
[1603]
[1605]
[1609]
Function:
[1610]
[1611]
[1612]
[1613]
[1614]
[1615]
[1616]
[1618]
[1620]
[1622]
[1630]
[1633]
[1634]
[1635]
[1638]
[1639]
[1650]
[1652]
[1653]
[1657]
[1660]
[1661]
[1662]
[1663]
[1664]
[1665]
[1667]
[1668]
[1669]
[1671]
[1672]
[1673]
[1674]
[1684]
Danfoss A/S © 06/2016 All rights reserved.
PCD 8 Write For Application
PCD 9 Write For Application
PCD 10 Write For Application
None
Motor Speed Unit
Motor Speed High Limit [RPM]
Operating hours
Running Hours
kWh Counter
Control Word
Reference [Unit]
Reference [%]
Status Word
Main Actual Value [%]
Custom Readout
Power [kW]
Power [hp]
Motor Voltage
Frequency
Motor current
Frequency [%]
Torque [Nm]
Motor Thermal
Motor Angle
Torque [%]
DC Link Voltage
Brake Energy /2 min
Heatsink Temp.
Inverter Thermal
SL Controller State
Control Card Temp.
External Reference
Feedback[Unit]
Digi Pot Reference
Feedback [RPM]
Digital Input
Terminal 53 Setting
Analog input 53
Terminal 54 Setting
Analog input 54
Analog output 42 [mA]
Pulse input 29 [Hz]
Pulse Input 33 [Hz]
Pulse Output 27 [Hz]
Relay output
Counter A
Counter B
Prec. Stop Counter
Comm. Option STW
