Troubleshooting
Bit hex
0 00000001
1 00000002
2 00000004
3 00000008
4 00000010
5 00000020
6 00000040
7 00000080
8 00000100
9 00000200
10 00000400
6 6
11 00000800
12 00001000
13 00002000
14 00004000
15 00008000
16 00010000
17 00020000
18 00040000
19 00080000
20 00100000
21 00200000
22 00400000
23 00800000
24 01000000
25 02000000
26 04000000
27 08000000
28 10000000
29 20000000
30 40000000
31 80000000
Table 6.6 Extended Status Word
36
EtherNet/IP
Dec Extended status word
(parameter 16-94 Ext.
Status Word)
1 Ramping
2 AMA running
4 Start CW/CCW
8 Slow down
16 Catch up
32 Feedback high
64 Feedback low
128 Output current high
256 Output current low
512 Output frequency high
1024 Output frequency low
2048 Brake check OK
4096 Braking max
8192 Braking
16384 Reserved
32768 OVC active
65536 AC brake
131072 Reserved
262144 Reserved
524288 Reference high
1048576 Reference low
2097152 Reserved
4194304 Reserved
8388608 Reserved
16777216 Reserved
33554432 Reserved
67108864 Reserved
134217728 Reserved
268435456 Reserved
536870912 Reserved
1073741824 Reserved
2147483648 Database busy
Danfoss A/S © 06/2016 All rights reserved.
Bit (hex) Communication option STW
(parameter 16-84 Comm. Option STW)
00000001 Parameterization OK.
00000002 Configuration OK.
00000004 Clear mode active.
00000008 Baud rate search.
00000010 Waiting for parameterization.
00000020 Waiting for configuration.
00000040 In data exchange.
00000080 Not used.
00000100 Not used.
00000200 Not used.
00000400 Not used.
00000800 MCL2/1 connected.
00001000 MCL2/2 connected.
00002000 MCL2/3 connected.
00004000 Data transport active.
00008000 Unused.
Table 6.7 Parameter 16-84 Comm. Option STW
NOTICE
Parameter 16-84 Comm. Option STW is not part of
extended diagnosis.
For diagnosis, read out the alarm words, warning words,
and extended status words via fieldbus or optional
fieldbus.
