Parameters
12-22 Process Data Config Read
Option:
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1697] Alarm Word 3
[3421] PCD 1 Read For Application
5 5
[3422] PCD 2 Read For Application
[3423] PCD 3 Read For Application
[3424] PCD 4 Read For Application
[3425] PCD 5 Read For Application
[3426] PCD 6 Read For Application
[3427] PCD 7 Read For Application
[3428] PCD 8 Read For Application
[3429] PCD 9 Read For Application
[3430] PCD 10 Read For Application
[3450] Actual Position
[3456] Track Error
12-28 Store Data Values
Option:
[0] Off
*
[2] Store all setups All parameter values in all set-ups are
12-29 Store Always
Option: Function:
[0] Off Deactivate the function which always stores received
*
parameter data in non-volatile memory (EEPROM).
[1] On Activate the function which always stores received
parameter data in non-volatile memory (EEPROM).
28
EtherNet/IP
Function:
Function:
The store function is inactive.
stored in the non-volatile memory.
Danfoss A/S © 06/2016 All rights reserved.
5.2.4 12-3* EtherNet/IP
12-30 Warning Parameter
Range: Function:
0 [0 - Read-only. Show the EtherNet/IP specific 16-bit
*
65535] status word.
Bit Description
0 Owned
1 Not used
2 Configured
3 Not used
4 Not used
5 Not used
6 Not used
7 Not used
8 Minor recoverable fault
9 Minor unrecoverable fault
10 Major recoverable fault
11 Major unrecoverable fault
12 Not used
13 Not used
14 Not used
15 Not used
Table 5.1 Bit Description
12-31 Net Reference
Show the reference source in Instance 21/71.
Option: Function:
[0] Off Reference from the network is not active.
*
[1] On Reference from the network is active.
12-32 Net Control
Show the control source in Instance 21/71.
Option: Function:
[0] Off Control via the network is not active.
*
[1] On Control via the network is active.
12-33 CIP Revision
Range: Function:
Size related [0 - 65535] Show the CIP revision of the option
*
software.
12-34 CIP Product Code
Range:
Size related [0 - 65535]
*
12-35 EDS Parameter
Range: Function:
0 [0 - 0] Configure the frequency converter via device net
*
and build the EDS-file.
Function:
Show the CIP product code.
