Table 4-12: Power Connector
Terminal
Center pin
Outer Ring
4.6.2 Board Current Measurements
The ADSP-21161N EZ-KIT Lite board provides two zero-ohm resistors that may
be removed to measure current draw.
voltage plane, and a description of the components on the plane.
Table 4-13: Current Measurement Resistors
Resistor
R168
R169
ADSP-21161N EZ-KIT Lite Evaluation System Manual
Connection
+7.5 VDC@2amps
GND
Voltage
Plane
VDDINT
Core Voltage of the DSP
VDDEXT
I/O Voltage of the DSP
Table 4-13
shows the resistor number, the
Description
4-17
