Specifications

Specifications
The following board specifications are covered in this section.
• "Power Supply" on page 2-16
• "Board Current Measurements" on page 2-16

Power Supply

The power connector supplies DC power to the EZ-KIT Lite board.
Table 2-6 shows the power supply specifications.
Table 2-6. Power Supply Specifications
Terminal
Center pin
Outer ring

Board Current Measurements

The ADSP-21160M EZ-KIT Lite board provides two zero-ohm resistors
that can be removed to measure current draw.
number and the voltage plane measurable at that location.
Table 2-7. Current Measurements
Resistor
R7
R6
2-16
www.BDTIC.com/ADI
Connection
+7.0V@2 amps
GND
Voltage Plane Description
Core voltage of the processor
VDD_EXT
IO voltage of the processor
VDD_INT
ADSP-21160 EZ-KIT Lite Evaluation System Manual
Table 2-7 shows the resistor
