• 3.5 mm headphone jack — Provides local audio out from the touchpanel.
•
Light sensor — Adjusts screen brightness as the ambient room lighting changes.
•
Configurable red and green status lights —Indicate the availability or call status of a
room.
•
Two high speed USB 2.0 ports — For future expansion
•
Automatic clock synchronization — Allows touchpanel to display the accurate time and
date.
•
Energy-saving features —
Adjustable sleep timer puts touchpanel into sleep mode
•
Motion detector wakes touchpanel
•
• Mounting options for tilt models (TG models):
Sit on a tabletop — weighted base allows up to 40° of tilt.
•
• Threaded holes in baseplate allow for secure mounting to a table.
Kensington lock support allows the touchpanels to be locked to a table or other flat
• ®
surface.
• Supports the optional SMA-1 Swivel Mount Adapter.
VESA FDMI Type D 100 mm mounting pattern standard can be used for VESA
•
mounting.
•
Mounting options for wall-mount models (MG models):
Mount on a wall, lectern, or any flat surface. The included mounting hardware enables
•
multiple mounting options.
• The optional back box, BB 700M can be used where local codes require a rear metal
enclosure.
• Fully customizable using Extron control system software — GUI Designer combined
with Global Configurator Plus, Global Configurator Professional, or Global Scripter.
• Supports the Extron Control App.
• Manage, monitor, and control this device remotely — Using GVE - GlobalViewer
Enterprise Resource Management software
