2.
If DHCP is on, press the
box opens:
Figure 10.
Alphanumeric Keypad
Use the keypad to enter a new name, which appears in the
3. If DHCP is disabled, set the unit IP address, subnet mask, gateway address, and DNS
server address.
a. Press the button for the address to be edited. A screen opens, showing the address
and a numerical keypad.
IP Address
1 9 2 1 6 8 2 5 4
1 2
4 5
7 8
0
Back
Figure 11. Numeric Pad for Setting IP Addresses
b. Select an octet and enter the 3-digit value (leading zeroes in the octet are ignored).
NOTES:
•
Octets can have any value between
•
If you attempt to enter an invalid number, for example
89 but the 2 cannot be entered.
enter the
• When a valid 3-digit value is entered, the next octet is automatically selected.
OK to save the changes and return to the Network screen or press Cancel to
c. Press
Network screen without saving the changes.
return to the
4. If you have changed any of the values in the
the background color of the button changes to blue. Press
Apply to apply the new values or press Revert to return to
the previous values without saving the changes. The button
returns to gray.
If you have not made any changes, the
buttons are grayed out.
Host Name button to edit the host name. The Host Name dialog
Clear
2 5 1
3
6
9
OK
Cancel
0 and 255 .
Network screen,
Apply and Revert
TLP Pro 1225, 1525, and 1725 Series • Setup Menu
Host Name text box.
892 , you are able to
0.0.0.10
Unsaved
0.0.0.10
Saved
Figure 12.
IP Address,
unsaved (top) and
saved (bottom).
