4.4

Verifying the Isocenter Calibration

4.4.1

Overview

General Use this function to verify whether the phantom was correctly aligned with the lasers during calibra-
Information tion.
Activating
Isocenter
Verification
Isocenter
Verification Screen
42
Before starting calibration verification, ensure that the computer cabinet has been
running for at least 60 minutes.
Steps
Select Move Isocenter Phantom To Current Isocenter in the Calibration screen (see
1.
Page 37), and confirm with Next.
2. An isocenter verification screen is shown.
Figure 15
Clinical User Guide Rev. 1.1, ExacTrac Infrared Monitoring Ver. 1.0
