Hardware Installation
6.1
Tools Needed
To install the NetGuardian, you'll need the following tools:
PC with Edit216F software
Phillips No. 2 Screwdriver
Small Standard No. 2 Screwdriver
6.2
Mounting
The NetGuardian mounts in a 19" rack or a 23" rack using the provided rack ears for each size. Two rack ear
locations are provided. Attach the appropriate rack ears in the flush-mount or rear-mount locations shown in above.
Note: Rack ears can be rotated 90° for wall mounting or 180º for other mounting options (not shown).
Wire Strippers/Cutter
Punch Down Tool (if 66 blocks are used)
The NetGuardian can be flush or rear-mounted
