12.4
ASCII Conversion
The information contained in Table 12.4.A is a list of ASCII symbols and their meanings. Refer to the bulleted list
below to interpret the ASCII data transmitted or received through the data port. Port transmit and receive activity can
be viewed from the Web browser interface.
•
Printable ASCII characters will appear as ASCII.
•
Non-printable ASCII characters will appear as labels surrounded by { } brackets (e.g. {NUL}).
•
Non-ASCII characters will appear as hexadecimal surrounded by [ ] brackets (e.g. [IF]).
•
A received BREAK will appear as <BRK>.
Abbreviation
NUL
SOH
STX
ETX
EOT
ENQ
ACK
BEL
BS
HT
LF
VT
FF
CR
SO
SI
Description
Abbreviation
Null
Start of Heading
Start of Text
End of Text
End of Transmission
Enquiry
Acknowledge
Bell
Backspace
Horizontal Tabulation
Line Feed
Vertical Tabulation
Form Feed
Carriage Return
Shift Out
Shift In
ASCII symbols
Description
DLE
Data Link Escape
DC
Device Control
NAK
Negative Acknowledge
SYN
Synchronous Idle
ETB
End of Transmission Block
CAN
Cancel
EM
End of Medium
SUB
Substitute
ESC
Escape
FS
File Separator
GS
Group Separator
RS
Record Separator
US
Unit Separator
SP
Space (blank)
DEL
Delete
BRK
Break Received
