Twisted Hobbys Veloxity Manual page 25

With a little bit of thin CA and Kicker,
join the two piece together in the
orientation shown.
Locate the other, similarily shaped
wood piece and install it as shown.
Install this piece with the glue wet.
Make sure that it is in alignment with
the fuselage.
Rev: 2015.11.30.v01a
Tack up Method will be used to join the
tail skid assembly to it's spot on the
end of the airframe. Apply a medium
skim coat to the mating areas of each
part and let set for about 5 minutes.
Locate the SFG's, two carbon 3x0.5x75
and two carbon 3x0.5x125 as pictured
above. Test t the carbon rectangles
into the pre-cut slots.
Once the Welders has tacked up join
the two pieces as shown
After verifying t, remove the carbon
rectangles and squeeze a little Welders
into the slots.
