1.2m Sbach 342
By RC Factory
Specifications
Wing span – 48" / length – 48" / AUW 24oz
250 - 450w outrunner motor (70g – 100g)
30 - 45 amp ESC / 3s 1600 – 2500mAh battery
4 ch radio / 4x Metal Gear 14g – 18g servos
11 x 4.7 – 12 x 5 prop
USA Distributor
Twisted Hobbys
www.twistedhobbys.com
Rev: 2012.09.16.v001a
1
Advertisement
Table of Contents
Related Manuals for Twisted Hobbys Sbach 342
Summary of Contents for Twisted Hobbys Sbach 342
-
Page 1: Specifications
1.2m Sbach 342 By RC Factory Specifications Wing span – 48” / length – 48” / AUW 24oz 250 - 450w outrunner motor (70g – 100g) 30 - 45 amp ESC / 3s 1600 – 2500mAh battery 4 ch radio / 4x Metal Gear 14g – 18g servos 11 x 4.7 –... -
Page 2: Table Of Contents
TABLE OF CONTENTS Page WARNING INFORMATION..............................3 SHIPPING DAMAGE................................3 OUR MISSION ..................................3 SAFETY NOTES ..................................4 IMPORTANT: PRIOR TO ANY ASSEMBLY ......................4 KIT CONTENTS ..................................5 OPTIONAL PARTS ..................................6 TOOLS & ADHESIVES NEEDED............................7 THE BUILD ....................................8 MOTOR & ESC..................................28 RECEIVER ....................................28 CENTER OF GRAVITY ................................29 CONTROL THROWS ................................29 3D Flight ..................................29 Sport ....................................29... -
Page 3: Warning Information
These instructions are suggestions only on how to assemble this model. There are other ways and methods to do so. Twisted Hobbys has no control over the final assembly, the materials and accessories used when assembling this kit, or the manner in which the assembled model, installed radio gear and electronic parts are used and maintained. -
Page 4: Safety Notes
SAFETY NOTES SAFETY NOTES SAFETY NOTES SAFETY NOTES Before assembling and flying this model, read carefully any instructions and warnings of other manufacturers for all the products you installed or used on your model, especially radio equipment and power source. Check thoroughly before ever flight that the airplanes’... -
Page 5: Kit Contents
kit contents kit contents kit contents kit contents some items shown are optional R C F a c t o r y 1 . 2 m S b a c h standard parts list: hardware packet: 1x - fuselage 1x - canopy 1x - backbone 1x –... -
Page 6: Optional Parts
Easy to install, each horn matches perfectly with Twisted Hobbys and TowerPro servo arms. Perfect choice for building and repairing your Twisted Hobbys EPP planes! This is the only adhesive you will ever need. Welder virtually bonds anything to anything! Clear, heavy-duty, flexible and water-proof when dry. -
Page 7: Tools & Adhesives Needed
Tools & & & & Adhesives Needed Tools Adhesives Needed Tools Tools Adhesives Needed Adhesives Needed • Tape Measure and Tape Measure and Ruler Ruler Tape Measure and Tape Measure and Ruler Ruler • Lighter Lighter Lighter Lighter • Small drill bits Small drill bits Small drill bits Small drill bits... -
Page 8: The Build
THE BUILD THE BUILD THE BUILD THE BUILD CONSTRUCTION METHODS: Building surface should be at least 2ft x 4ft and flat. Weights or some small heavy objects will be handy for holding things in place during the time glue is setting. Three types of glue are used for the build, Welders glue is use for most areas, Hot Glue for the electronics and CA in the construction of the control rods and stiffners. - Page 9 STEP STEP STEP STEP – – – – C C C C – – – – Locate the wing the wing halves and the fuseslage backbone. Note that there are little tabs that help to position the wing halves correctly. You should be looking at the bottom of the wings, and the cutout for the elevator should be facing down, this...
- Page 10 STEP STEP STEP STEP – – – – C C C C – – – – (con’t) Apply welder glue to the wing root and mating area of the fuselage backbone. Spread the bead of glue to create a nice even coat. Use and old credit card or business card to prevent your fingers from becoming full of glue.
- Page 11 STEP STEP STEP STEP – – – – D D D D – – – – (con’t) Press the spar into the slit you just cut insuring that is fully contained. Make sure the wing is perfectly flat on the workbench by slightly pressing down on everything.
- Page 12 STEP STEP STEP STEP – – – – E E E E – – – – (con’t) From the underside of the Elevator install the 1x5x245 strip into the precut slot of the fixed part of the elevator so the spar will be flush with the surface.
- Page 13 STEP STEP STEP STEP – – – – F F F F – (con’t) Once the Welders has tacked up, lay both pieces on a piece of either wax or parchment paper, and slide the two pieces together. Use the extreme front and rear of the Canopy corners as a guide to line up with the corners of the cut outs in the Fuselage.
- Page 14 STEP STEP STEP STEP – – – – G G G G – (con’t) Notice that the Stirrups are keyed to the plate and all three parts should fit nicely into the exisitng holes and slot you just made. Also notice that the slot in the Stirrup should be toward the rear of the plane.
- Page 15 STEP STEP STEP STEP – – – – H H H H – Locate the lower part of the Fuselage and test fit into the slots of the belly side of the backbone. Apply a thin layer of Welders to the contact areas of both pieces, and smooth to a thin layer and allow to tack up.
- Page 16 STEP STEP STEP STEP – – – – H H H H – (con’t) With the belly of the plane facing up, test fit the Elevator. Check with a tape measure that when all butted up flush that the tips of the Elevator from both sides are the same distance to the wing tips.
- Page 17 STEP STEP STEP STEP – – – – H H H H – (con’t) Locate the Anti-Torsional strips. For a more streamlined look you can trim and bevel one end of each strip as shown. Tack gluing method will be used to attach the Strips, but in order to get the glue in the right spots, do the followning;...
- Page 18 STEP STEP STEP STEP – – – – I I I I – Drill a 3mm hole in the end of each Landing Gear Strut for the wheel axle. Also enlarge the hole in the wheel. STEP STEP – – – – J J J J – STEP STEP Assemble in the following order - the...
- Page 19 RADIO GEAR RADIO GEAR RADIO GEAR RADIO GEAR In the next step you will start installing radio gear, strongly suggested that before doing so that all the electronics are hooked up and tested. Start with a fresh Model Program on your Transmitter if appropriate, make sure all the trims and sub trims are zero, and that all the travels are `100%.
- Page 20 OPTIONAL part avaible from enlarge screw hole Twisted Hobbys made specifically for the servos in the power sets. Center the Servo and the Aileron. Aileron center will be when the trailing edge...
- Page 21 STEP STEP STEP STEP – – – – L L L L – In this step we will glue the firewall and upper Fuselage to the wing and backbone assembly. Cutting the holes for the Rudder Servo at this time will make installing the servo in Step O easier.
- Page 22 STEP STEP STEP STEP – – – – L L L L – (con’t) Once the glue on flat surfaces has tacked up, apply Welders to the sides of the tabs and the motor mount than assemble. Check for squareness and tweek from side to side if necessary.
- Page 23 STEP STEP STEP STEP – – – – M M M M – (con’t) Cut horizontal and vertical slits into the bottom of the Rudder control surface to accommodate the tail wheel holder and the bottom rudder hinge. Make sure that there will be enough room for the tail wheel to clear the bottom of the rudder control surface.
- Page 24 STEP STEP STEP STEP – – – – M M M M – (con’t) Remove the Rudder from the fuselage and glue the hinge pieces into their respective places being mindful of their locations as noted in the previous step. Pressure on the glue joints can be maintained with some high tack masking tape.
- Page 25 STEP STEP STEP STEP – – – – N N N N – (con’t) Make a reference line on the wing, parallel to the centerline of the fuselage. Lay down a thin bead of Welders on the top and bottom of the wing along the reference line, and on the inside of the SFG, spread smooth and allow to tack up.
- Page 26 STEP STEP STEP STEP – – – – N N N N – (con’t) Install the Elevator horn and control rod with z-bend as shown to the left. Make a cut out as shown approx 1 inch behind the aileron for the servo, center electronically, attach the horn (item 3), center the Elevator, now cut any extra from the length of the...
- Page 27 STEP STEP STEP STEP – – – – O O O O – Install the Rudder Servo. Make a cut out now, if not done earlier, in the area of the exsisting slot. Make sure the servo is electronically centered, attach the horn (item 6) and install the servo.
-
Page 28: Motor & Esc
MOTOR MOTOR MOTOR MOTOR & & & & ESC Attach the “X” mount to your motor. Make sure the screws are flush and use thread locker. If the screws are not flush, counter sink the holes a little deeper with a 90 deg. Counter sink. -
Page 29: Center Of Gravity
Center of Gravity Center of Gravity Center of Gravity Center of Gravity 110mm back from mm back from mm back from mm back from Leading Edge Leading Edge Leading Edge Leading Edge of the Wing at the Fuselage of the Wing at the Fuselage of the Wing at the Fuselage of the Wing at the Fuselage Locate the battery last, and use it to establish the proper Center of Gravity. -
Page 30: Pre-Flight & Testing
Storage or significant reduction with the motor in a hot car could also cause damage. running, resolve and re-test before flying. Be safe and enjoy, thank you again for purchasing a Twisted Hobbys’ Product! Rev: 2012.09.16.v001a... -
Page 31: Notes & S/U Sheet
NOTES NOTES NOTES NOTES & & & & s/u Sheet s/u Sheet s/u Sheet s/u Sheet Rev: 2012.09.16.v001a...
