Twisted Hobbys Veloxity Manual page 21

Repeat the entire process with the left As with the right side, make sure and
Tail control rods are next, locate the
aileron servo. when gluing in the aileron control horn
remaining two 1.8mm dia carbon rods,
that the prole of the horn matches the
2 ferrules, 4 ball links and the control
prole of the hinge cut shape.
surface horns pictured above. Install
the servo horns as shown.
Attach a ball link to the free end, again Repeat the previous two steps with the
Starting with the shorter rod, install a
brass end and ball link as was done sanding a little to get the link to slide longer rod, and cut to length from the
with the aileron control rod, and cut to on far enough so that you get 149mm center of the ball to 164mm long.
144mm from the center of the hole in form center of hole to center of hole.
Glue with thin CA and Kicker
the brass ball to the end.
page 21
Rev: 2015.11.30.v01a
