be routed outdoors, connect a lightning arrester to the cable before you plug the cable into the
port.
Lightning protection
To protect the firewall from lightning better, follow these guidelines:
•
Make sure the grounding cable of the chassis is reliably grounded.
•
Make sure the grounding terminal of the AC power receptacle is reliably grounded.
•
Install a lightning arrester at the input end of the power module to enhance the lightning
protection capability of the power module.
Power supply
Verify that the power system at the installation site meets the requirements of the power modules,
including the input method and rated input voltage. For more information, see
views and technical
Installation tools
All installation tools are user supplied.
Crimping tool
ESD wrist strap
Accessories
Grounding cable
Mounting brackets for the
F1020/F1030/F1050/F1060/
F1070/F1080/F1090
specifications."
Phillips screwdriver
Multimeter
Mounting bracket for
the F1005/F1010
Needle-nose pliers
Knife
M6 screw
(user supplied)
Rubber feet
6
"Appendix A Chassis
Wire stripper
Diagonal pliers
Cage nut (user
M4 screw
supplied)
Power cord
Cable tie (user
retainer clip
supplied)
