Starting The Firewall And Observing The Initial Startup Conditions - H3C SecPath F10 0 Series Installation Manual

Starting the firewall and observing the initial startup
conditions
Turn on the circuit breakers to power on the firewall.
1.
Observe the initial startup conditions to verify that the firewall starts up correctly.
2.
The LEDs on the front panel indicate that the device is operating correctly. For more
information about LEDs, see
The fan blades are rotating and air is exhausted from the air outlet vents.
The configuration terminal displays the following information:
System is starting...
Press Ctrl+D to access BASIC-BOOTWARE MENU...
Press Ctrl+T to start heavy memory test
Booting Normal Extended BootWare
The Extended BootWare is self-decompressing......Done.
****************************************************************************
*
*
*
****************************************************************************
Compiled Date
CPU Type
CPU Clock Speed
Memory Type
Memory Size
Memory Speed
BootWare Size
Flash Size
CPLD_A Version
CPLD_B Version
PCB Version
BootWare Validating...
Press Ctrl+B to access EXTENDED-BOOTWARE MENU...
Loading the main image files...
Loading file
flash:/f1000fw-cmw710-system-E9308.bin.............................
........................Done.
Loading file flash:/f1000fw-cmw710-boot-E9308.bin....
Image file flash:/f1000fw-cmw710-boot-E9308.bin is self-decompressing.......
......................................................Done.
System image is starting...
Cryptographic Algorithms Known-Answer Tests are running ...
CPU 0 of slot 1 in chassis 0:
Starting Known-Answer tests in the user space.
Known-answer test for SHA1 passed.
"Appendix B LEDs."
H3C F1080 BootWare, Version 1.04
: Sep 10 2014
: xxx
: 1000MHz
: DDR3 SDRAM
: 4096MB
: 1332MHz
: 768KB
: 8MB
: 2.0
: 2.0
: Ver.A
26
*
*
*
Done.
