One hard disk slot.
Figure 39 Front panel
(1) Hard disk slot
(3) 10/100/1000BASE-T copper ports
(5) Console port
(7) Management Ethernet port (0/MGMT)
Figure 40 Rear panel
(1) Power receptacle
(3) Interface module slot 2 (not supported)
F1030/F1050/F1060
The F1030/F1050/F1060 firewall provides the following ports on the front panel:
•
Sixteen 10/100/1000BASE-T autosensing Ethernet copper ports.
•
Eight 1000BASE-X fiber ports.
•
Two USB ports.
•
One console port.
•
One hard disk slot.
Figure 41 Front panel
(1) Hard disk slot
(3) 10/100/1000BASE-T copper ports
(5) Console port
(7) Management Ethernet port (0/MGMT)
(2) LEDs
(4) 1000BASE-X fiber ports
(6) USB ports
(2) Interface module slot 1
(4) Grounding screw
(2) LEDs
(4) 1000BASE-X fiber ports
(6) USB ports
41
