AC power modules

PSR150-A1
The PSR150-A1 power module provides a maximum output power of 150 W.
Figure 51 PSR150-A1 power module
(1) Handle
PSR250-12A1
The PSR250-12A1 power module provides a maximum output power of 250 W.
Figure 52 PSR250-12A1 power module
(1) Latch
(3) Handle

DC power modules

PSR150-D1
The PSR150-D1 power module provides a maximum output power of 150 W.
1 2
(2) Power receptacle
(2) Status LED
(4) Power receptacle
