Before you move the firewall, remove all cables and mounting brackets.
•
For long-distance transportation, remove all the field-replaceable units (FRUs), such as power
modules and interface modules, and package them separately, and install the filler panels
supplied with the firewall. For short-distance transportation, make sure all the FRUs are
securely seated in the slots and the screws are fastened.
•
When you move or lift the firewall chassis, support the bottom of the chassis, rather than
holding any FRU. Make sure the accessories of the firewall are not lost or damaged during
firewall moving.

Examining the installation site

The firewall can only be used indoors. To make sure the firewall operates correctly and to prolong its
service lifetime, the installation site must meet the following requirements.

Weight support

Make sure the floor can support the total weight of the rack, chassis, modules, and all other
components. For more information, see "Dimensions and weights."

Temperature and humidity

Maintain appropriate temperature and humidity in the equipment room.
•
Lasting high relative humidity can cause poor insulation, electricity leakage, mechanical
property change of materials, and metal corrosion.
•
Lasting low relative humidity can cause washer contraction and ESD and bring problems
including loose captive screws and circuit failure.
•
High temperature can accelerate the aging of insulation materials and significantly lower the
reliability and lifespan of the firewall.
For the temperature and humidity requirements of the firewall, see
Table 1 Temperature/humidity requirements
Temperature
•
Operating:
Without hard disks: 0°C to 45°C
(32°F to 113°F)
With hard disks: 5°C to 40°C
(41°F to 104°F)
•
Storage: –40°C to +70°C (–40°F to
+158°F)

Cleanliness

Dust buildup on the chassis might result in electrostatic adsorption, which causes poor contact of
metal components and contact points, especially when indoor relative humidity is low. In the worst
case, electrostatic adsorption can cause communication failure.
Table 2 Dust concentration limit in the equipment room
Substance
Dust particles
Relative humidity
•
Operating:
Without hard disks: 5% to 95%, noncondensing
With hard disks: 10% to 90%, noncondensing
•
Storage: 5% to 95%, noncondensing
Concentration limit (particles/m
4
≤ 3 × 10 (No visible dust on desk in three days)
3
Table 1.
