ADC Soneplex Broadband System Operation And Maintenance Manual page 68

Summary: This procedure provides instructions for displaying the status of the RLX or
RLXIOR modules installed in the selected chassis.
Note: The RLXIOR is displayed as "RLX" in the Craft Interface menus and screens.
Note: Press CONTROL-A for help information about moving around and editing fields.
1. Use the arrow keys to select Display RLX Status from the Display Status menu. Press Enter
or Return. A Display RLX Status screen is shown in
2. Move to the Group toggle field. Select group number 1, 2, 3, 4, 5, 6, or 7.
3. Move to the Slot toggle field. Select slot number 1, 2, 3, or 4.
Reference: TAD-106
Stop! You have completed this procedure.
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
RLX AND RLXIOR STATUS DISPLAY
Access Identifier
RLX STATUS
Group: 1
Circuit ID:
DS1 Lpbk Active: NO
Customer LOS: NO
Network LOS: NO
DS1 Line Code: AUTO-NR-B8ZS
DS1 Frame Format: AUTO-NR-ESF
DS1 BER Thresh Exceeded: NO
Press CONTROL-A For Assistance
Figure 509-1. RLX Status Screen (Typical)
Figure 509-1.
Slot: 1
© 2000, ADC Telecommunications, Inc.
DLP-509
Page 1 of 1
6180-B
2-45
