8. Repeat entire procedure for each RLX module.
Stop! You have completed this procedure.
NOT USED
SPAN POWER
CLOSED = ON
OPEN = OFF
TRANSMIT LINE BUILDOUT
CLOSED, CLOSED = 22.5 DB
CLOSED, OPEN = 15 DB
OPEN CLOSED = 7.5 DB
OPEN, OPEN = 0 DB
SA2
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
SA2 SA3
1 2 3 1 2 3
OPEN OPEN
CONFIGURATION
SWITCH PLACEMENT
SA3 SA3-1
Figure 525-1. Version A RLX Configuration Switches
SA3-1
1 2 3
OPEN
DSX LINE EQUALIZATION
OPEN, OPEN, OPEN
CLOSED, OPEN, OPEN
OPEN, CLOSED, OPEN
CLOSED, CLOSED, OPEN
OPEN. OPEN, CLOSED
NID LOOP CODE RECOGNITION
CLOSED = ENABLE
OPEN = DISABLE
© 2000, ADC Telecommunications, Inc.
DLP-525
Page 3 of 6
= 0 TO 133 FT
= 133 TO 266 FT
= 266 TO 399 FT
= 399 TO 533 FT
= 533 TO 655 FT
6262-A
2-83
