Note: In the DS1 Performance Reports screens,
102-2 (DS1 Daily), Figure 102-3
apply to the entire time period (e.g., 00:15), not just the statistics that appear on their
respective lines. In addition, the headings shown over each column apply respectively to
each statistic in the column. For example, in
column, first row; "CVL" applies to the first column, second row; and "ESL" applies to
the first column, third row.
Note: In Figure 102-1 (DS1 15-Minute),
Summary), Figure 102-4
(HDSL Summary), certain status abbreviations are used and are described below:
• COMPL means "Completed".
• PRTL means "Partial" when all the statistics from the time period have not yet been
compiled, or when data has been lost.
• NA means "Not Applicable" when SF framing is in use.
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
Figure 102-1
(DS1 Summary), NE (Near End) and FE (Far End)
Figure
Figure 102-2
(HDSL 15-Minute), Figure 102-5
Page 2 of 11
(DS1 15-Minute),
102-1, "FCP" applies to the first
(DS1 Daily), Figure 102-3
(HDSL), and Figure 102-6
