ADC Soneplex Broadband System Operation And Maintenance Manual page 57

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DLP-504
Page 2 of 2
PIN NAME
1 FG
2 TD
3 RD
7 SG
2-34
© 2000, ADC Telecommunications, Inc.
Table 504-1. MPU Craft Port Wiring
SOURCE CIRCUIT CCITT
– 101
DTE 103
DCE 104
– 102
Cable uses Type DB-25 Male connector.
Overall shielding, common for all leads.
Use 26 AWG or larger wire, stranded pairs.
M
P
U
STATUS
C
R
A
F
T
RESET
1749-B
Figure 504-1. MPU Front Panel
CIRCUIT EIA FUNCTION
AA Frame Ground
BA Transmitted Data
BB Received Data
AB Signal Ground
