ADC CopperTen Modular Jack Specification Sheet

TrueNet
®
CopperTen Modular Jack
®
An integral part of ADC's TrueNet
UTP structured cabling system to enable 10 Gigabit Ethernet over a full 100 meters. Installed
in high-performance networks worldwide, the system's patent-pending design minimizes alien
crosstalk and insertion loss and meets the performance requirements of IEEE 802.3an and
TIA/EIA 568-B.2-10 standards.
The CopperTen modular jack features LSA-PLUS
secure and reliable connection available. CopperTen jacks are available in 10 colors for unique
port identification and mount in any of ADC's modular station outlets.
Features:
• Forty-five degree silver-plated IDCs provide secure, reliable gas-tight connections
• Integrated conductor manager separates individual cable pairs for improved performance
• Accepts KRONE ® or 110-style wire termination tools
• Universal A/B wiring label
• UL 1863 listed
• Product Warranty — 20 years
w w w . a d c . c o m • + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 • 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Structured Cabling System, CopperTen
®
silver-plated 45° angled contacts for the most
®
is the world's first
®
