Table 101-1. Soneplex Broadband System (V5) Specifications, continued
PARAMETER
Version D and later HLXC
Modules
Loop Loss
Loop Types
Transmission:
Format
Line Impedance
Loop Power Output Voltage
Return Loss
Total Signal Power
B1 HLXR
DS1 Interface:
Input / Output Signals
Frequency
HDSL Interface:
Format
Impedance
Loop Loss
Loop Type
Output Signal Level
Return Loss
Power
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
SPECIFICATION
< 35 dB @ 196 kHz
Two-pair, single or mixed gauges With or without bridged taps
Two 784 kbps full duplex pairs,
2B1Q modulation
135 ohms nominal
–132 ± 5 VDC (without HRX)
±130 VDC (with HRX)
>20 dB
+13.5 dBm ± 0.5 dBm
Per ANSI T1-403
1.544 Mbps
Two 784 kbps full duplex pairs,
2B1Q
135 ohms
<35 dB
Two pair, single or mixed gauges With or without bridged taps
+13.5 dBm
>20 dB
–42 to –56 VDC (local)
85 to 130 VDC (line)
– –
TAD-101
Page 3 of 9
REMARKS
135 ohm termination
Balanced
40 kHz to 200 kHz
196 kHz
40 to 200 kHz
(continued)
