ADC Soneplex Broadband System Operation And Maintenance Manual page 117

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DLP-529
Page 3 of 4
2-94
© 2000, ADC Telecommunications, Inc.
UNIT CONFIGURATION
1. MUX Configuration
2. ODS2 Configuration
3. QLX Configuration
4. HLX Configuration
5. DLX Configuration
6. RLX Configuration
Display/Edit All MUX Configuration Parameters
Press CONTROL-A For Assistance
Figure 529-3. Unit Configuration Menu
DS3MUX CONFIGURATION
Unit Equip State
Unit Service State
MUX Protect Status
Facility Service State: OUT OF SERVICE
Transmit LBO Setting
DS1 Loopback Mode
DS3 Framing Format Status (Display Only): M13
Press CONTROL-A For Assistance
Figure 529-4. DS3 MUX Configuration Screen
: EQUIPPED
: OUT OF SERVICE
: UNPROTECTED
: IN
: C-BIT
8105-B
6660-C
