ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DLP-526
Page 2 of 2
Welcome to ADC: SONEPLEX Shelf Interface
Display Shelf, MUX, ODS2, QLX, HLX, DLX, RLX Status
2-88
© 2000, ADC Telecommunications, Inc.
Welcome to ADC: SONEPLEX Shelf Interface
(C) Copyright 1997 ADC Telecommunications, Inc.
Enter User Name:
Figure 526-1. Craft Interface Logon Screen
(C) Copyright 1997 ADC Telecommunications, Inc.
SONEPLEX MAIN MENU
1. Alarms
2. Display Status
3. Unit Configuration
4. System Administration
5. System Configuration
6. System Maintenance
7. Performance Monitoring
Press CONTROL-A For Assistance
Figure 526-2. Craft Interface Main Menu
Version 5.1.2
10454-A
Version 5.1.2
6659-D
