ADC Soneplex Broadband System Operation And Maintenance Manual page 297

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
TAD-104
Page 9 of 11
Table 104-4. Compressed TBOS Scan Display Definitions
DISPLAY UNIT TYPE
Critical Alarm Shelf
Major Alarm Shelf
Minor Alarm Shelf
Remote Alarm Shelf
Power Alarm Shelf
HSW Eqpt Alm N/A
HSP Eqpt Alm N/A
HWS Fac Alm N/A
HSP Fac Alm N/A
MXW Eqpt Alm DS3 MUX
MXP Eqpt Alm
MXW Fac Alm DS3 MUX
MXP Fac Alm
Dx a L/R Alarm
ODS2 & QLX
Dx L/R Alarm HLX
Dx L/R Alarm RLX
Dx L/R Alarm DLX
HSKPx Rmt Alm ODS2 & QLX
HSKPx Rmt Alm HLX
HSKPx Rmt Alm RLX
HSKPx Rmt Alm DLX
Lx Lcl Alarm ODS2 & QLX
Lx Lcl Alarm HLX
Lx Lcl Alarm RLX
Lx Lcl Alarm DLX
Lx Rmt Alarm ODS2 & QLX
Lx Rmt Alarm HLX
Lx Rmt Alarm RLX
Lx Rmt Alarm DLX
a "x" represents the Soneplex chassis (shelf) slot number
2-274
© 2000, ADC Telecommunications, Inc.
DESCRIPTION
Critical Alarm shelf summary
Major Alarm shelf summary
Minor Alarm shelf summary
Remote Alarm shelf summary
Shelf Power A or B input failure (but not both)
Not Applicable for this release
N/A for this release
N/A for this release
N/A for this release
Unit Fail, MPU COMM Fail, DS3 TX LOS, or (SISTER COMM Fail and not SISTER
MPU COMM Fail)
DS3 RX LOS, DS3 RX OOF, DS3 Loopback
DS2 Optical COMM Fail, DS2 Optical LOS, DS2 Optical OOF, DS2 Optical BER,
DS1 RX LOS, DS1 Loopback
DS1 RX LOS, HDSL LOSW, HDSL BER, HDSL SNR, DC Loop Continuity (if HLXR
is line powered), DS1 Loopback
DS1 RX LOS, DS1 RX LOF, DS1 Loopback
DS1 RX LOS, DS1 BER, DS1 Loopback
Slot number is x-1: HSKP1 alarm reporting by QFLC or QLX working.
Slot number is x-2: HSKP2 alarm reporting by QLX working only.
Slot number is x-3: HSKP3 alarm reporting by QFLC or QLX working.
Slot number is x-4: HSKP4 alarm reporting by QLX working only.
Remote Housekeeping Alarm A or B reported by an HLXR
N/A
N/A
Unit Fail, MPU COMM Fail, Laser Degrade, DS1 TX LOS, or (SISTER COMM Fail
and not SISTER MPU COMM Fail)
Unit Fail, MPU COMM Fail
Unit Fail, MPU COMM Fail
MPU COMM Fail
Remote Unit Fail
N/A
N/A
N/A
