ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DLP-541
Page 7 of 16
Note: Do not perform a DS3 loopback when the Soneplex Broadband chassis
is connected to a DS3 CAM unit in the Soneplex CCAS system.
Unit Location -
COMMANDS:
Loopback:
STATUS:
Unit Type:
-------------->|--+
NETWORK
DS1
<--------------|<-+
Programmable Loopback Armed State: ARMING DISABLED
2-136
© 2000, ADC Telecommunications, Inc.
High Speed Loopback Status/Commands
Unit Location - LOCAL
===========
COMMANDS:
Loopback : ACT NET
STATUS:
Unit Type: DS3MUX
+---------+
|
----------------->|----+
|
NETWORK DS3 |
|
<-----------------|<---+
|fac
+---------+
Press CONTROL-A For Assistance
Figure 541-5. DS3 MUX Network Loopback Screen
Low Speed Loopback Status/Commands
Group: 4
LOCAL REPEATER
========== ==========
N/A
HLXC NONE
+---------+
| |
+->|---------------------------->|---------|------------->
| | | |
| | | | HDSL
| | | |
+--|<----------------------------|<--------|<-------------
|net cust|
+---------+
Press CONTROL-A For Assistance
Figure 541-6a. HLXC Customer Loopback Screen
|
|----------------->
| |
| | DEMUX
| |
|<-----------------
term|
DS1#: 1
REMOTE
==========
HLXR
+---------+
| |
| |
| |
| |
|net cust|
+---------+
6666-C
CUSTOMER
DS1
11381-A
