ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
TAP-102
Page 3 of 11
MON TYPE
MEANING
CVL
Code Violation Line
LOSS
Loss Of Signal
Second
ESL
Errored Second Line
SESL
Severely Errored
Second Line
FCP
Failure Count Path
CVP
Code Violation Path
AISSP
AIS Second Path
SASP
SEF/AIS Second Path
ESP
Errored Second Path
SESP
Severely Errored
Second Path
Note: DS1 Path Parameters are collected at the HLXC for both directions, as shown in
Note: Far-end parameters are not derived from defects detected in the incoming signal but rather from the
PRM (Performance Report Messages) embedded in the incoming signal from the far end. A Remote Alarm
Indication condition disallows reception of a valid PRM. The framing format must be ESF for FEND
information to be transmitted and displayed.
Note: For complete information on counts, refer to ANSI T1.231.
2-302
© 2000, ADC Telecommunications, Inc.
Table 102-1. DS1 Mon Type Descriptions
LOCATION DESCRIPTION
NEND
Count of Bipolar Violations (BPV) and excessive
zeros (EXZ) in the DS1 signal. Note: The maximum
rate of indications across HDSL loops that the far end
can report is 166.7 BPV per second (10,000 per
minute).
NEND
A second in which one or more Loss Of Signal defects
occurred.
NEND
A second in which there occurred one or more BPVs,
one or more EXZs, or one or more LOS defects.
NEND
A second in which more than some user specified
value of CVLs or one or more LOS defects occurred.
NEND
A count of Loss Of Frame (LOF) or Alarm Indication
Signal (AIS) failures within the interval. A failure is
counted when the failure condition transitions from
OFF to ON. Failure count is independent of the
duration (in seconds) of the failure condition.
NEND
Count of (FE) Frame sync Errors in SF format or
count of CRC errors in ESF format.
NEND
A second containing one or more AIS defects.
NEND
A second containing one or more AISSPs or one or
more SEF (Severely Errored Framing/OOF) defects.
NEND
SF framing format: this is a second in which there
occurred one or more FE events, one or more SEF
defects, or one or more AIS defects.
ESF framing format: this is a second in which there
occurred one or more CVP errors, one or more SEF
defects, or one or more AIS defects.
NEND
SF framing format: this is a second in which there
occurred more than eight FE events, one or more SEF
defects, or one or more AIS defects.
ESF framing format: this is a second in which there
occurred more than some user specified value of CVP
errors, one or more SEF defects, or one or more AIS
defects.
Figure
102-7.
(continued)
