ADC Soneplex Broadband System Operation And Maintenance Manual page 130

FIELD TYPE
Group Toggle 1, 2, 3, 4, 5, 6, or 7
Slot Toggle 1, 2, 3, or 4
Unit Equip State Toggle Equipped
Unequipped
Unit Service State Toggle IS (In-Service)
OOS (Out-Of-Service)
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DLX CONFIGURATION
Group: 5
Unit Equip State: EQUIPPED
Unit Service State: IS
T1 Provision: YES
T1 Service State: OOS
T1 Line Code: AMI
Pulse Equalization: 0-133 FT.
T1 BER Threshold: 1E-7
Loopback Timeout Period: 0
Circuit ID:
Press CONTROL-A For Assistance
Figure 532-1. DLX Configuration Screen
Table 532-1. DLX Configuration Fields
OPTIONS
Slot: 1
minutes
DESCRIPTION
Specifies the module's group
number designated on the chassis.
Specifies the module's slot number
designated on the chassis. Refer to
TAD-106 (Access Identifier).
Establishes communication with
MPU. Module must be set to
EQUIPPED before remaining
selections are allowed.
No communication with MPU.
Places the unit in service. This field
must be set to IS for reporting of
equipment alarms.
Removes unit from service and
stops equipment alarm reporting by
the MPU.
© 2000, ADC Telecommunications, Inc.
DLP-532
Page 2 of 3
6126-C
DEFAULT
1
1
UNEQUIPPED
OOS
(continued)
2-107
