ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DLP-507
Page 2 of 2
9. On FC connectors, push the connector into the adapter and screw the threaded cap
clockwise onto the adapter to complete the connection.
10. Connect SC connector by aligning the housing key with the slot in the adapter. Push the
connector into the adapter until a click is heard/felt indicating that the latching system is
engaged. When connector is fully engaged, the white stripes on the sides of the connector
housing should be hidden inside the adapter.
Stop! You have completed this procedure.
2-43
