ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DLP-548
Page 1 of 5
Summary: This procedure provides instructions for displaying the status of the HLX modules
installed in the central office chassis, the associated HLX modules at the remote end of the
circuit, and the HRX modules.
Note: Press CONTROL-A for help information about moving around and editing fields.
1. Use the arrow keys to select Display HLX Status from the Display Status menu. Press Enter
or Return.
2. Use the arrow keys to select HLX Status from the Display Status menu. Press Enter or
Return. Refer to
displayed on the screens.
3. Move to the Group toggle field. Select group number 1, 2, 3, 4, 5, 6, or 7.
TAD-106
Reference:
4. Move to the Slot toggle field. Select slot number 1, 2, 3, or 4.
Stop! You have completed this procedure.
HLXC/HLXR MPU SOFTWARE
SYSTEM TYPE VERSION
No HRX V5.1
One HRX V5.1
One or two V5.2
HRXs
Note: If one or no HRX is present in a two-repeater system, or no HRX is present in a one-repeater
system, the screens will show "N/A" in the related HRX column.
2-160
© 2000, ADC Telecommunications, Inc.
HLX AND HRX STATUS DISPLAY
Table 548-1 for descriptions of status screens, and status locations
Access Identifier
Table 548-1. Status Locations
STATUS
SCREEN
HLX Status
HLX/HRX
Status
HLX/HRX
Status
SCREEN STATUS
FIGURE LOCATIONS
Figure 548-1 N/A
Figure 548-2 C-SIDE,
R-SIDE
Figure 548-3 CRP1, RRP1,
CRP2, RRP2
STATUS LOCATION
DESCRIPTIONS
None
Figure 548-4
Figure 548-5
