6. Move to the Mon Type Alarms toggle fields. The following selections are possible:
• Critical Allows notification of all Critical, Major, Minor, and Event alarms as they
occur.
• Major Allows notification of all Major, Minor, and Event alarms as they occur.
• Minor Allows notification of all Minor and Event alarms as they occur.
• Event Allows notification of all events as they occur.
TAP-101
Reference:
7. Assign the selections by pressing Enter or Return.
8. Repeat Steps 3 through 7 for each applicable DS1 signal in the chassis.
Note: Pressing CONTROL-C and confirming with the Y key removes all threshold
values and alarm level information from the database for the group and slot selected.
Stop! You have completed this procedure.
Group: 1
15 MINUTE
MON ============== ================
TYPE THRSH ALM LVL
==== ===== ======== ======= ========
FCP 5 EVENT
CVL 13340 EVENT
ESL 65 EVENT
SESL 10 EVENT
LOSS 10 EVENT
CVP 13340 EVENT
ESP 65 EVENT
SESP 10 EVENT
UASP 10 EVENT
SASP 10 EVENT
CVs PER SESL: 1544
Press CONTROL-A For Assistance, CONTROL-C To Clear All PM Counts
* Indicates valid range of values for selected field. See
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
Alarm Troubleshooting
DS1 PERFORMANCE MONITORING CONFIGURATION
Circuit: 1 Circuit ID:
DAILY
MON
THRSH ALM LVL TYPE
======== ===== ======== ======= ========
480 EVENT AISSP
133400 EVENT FCP-FE
648 EVENT ESL-FE
100 EVENT CVP-FE
100 EVENT ESP-FE
133400 EVENT SESP-FE
648 EVENT UASP-FE
100 EVENT CSSP-FE
100 EVENT SEFSP-FE 10
100 EVENT
CVs PER SESP: 330
Figure 556-1. DS1 PM Configuration Screen
15 MINUTE DAILY
============== ================
THRSH ALM LVL THRSH
10 EVENT 100
5 EVENT 480
65 EVENT 648
13340 EVENT 133400
65 EVENT 648
10 EVENT 100
10 EVENT 100
10 EVENT 100
EVENT 100
CVs PER SESP-FE: 330
Table 556-1.
© 2000, ADC Telecommunications, Inc.
DLP-556
Page 2 of 3
ALM LVL
EVENT
EVENT
EVENT
EVENT
EVENT
EVENT
EVENT
EVENT
EVENT
6146-B
2-181
