Specification - ADC Soneplex Broadband System Operation And Maintenance Manual

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
TAD-101
Page 2 of 9
Table 101-1. Soneplex Broadband System (V5) Specifications, continued
PARAMETER
DS3 Interface (DS3 MUX)
DS3 Input Level
DS3 Transmit Power Level
Format
Impedance
Line Code
Line Rate
Maximum Span
DS3 Interface (D1 DS3 MUX)
DS3 Input Level
DS3 Transmit Power Level
Format
Impedance
Line Code
Line Rate
Maximum Span
DLX Module
Format
Input Impedance
Input Signal Level
Line Code
Line Rate
Output Pulse
Output Signal Level
C1 HLXC Module
Loop Loss
Loop Types
Transmission:
Format
Line Impedance
Loop Power Output Voltage
Return Loss
Total Signal Power
2-250
© 2000, ADC Telecommunications, Inc.

SPECIFICATION

+5.7 dBm to –7.3 dBm
–1.8 to +5.7 dBm
Bipolar, Return to Zero
75 ohms (nominal)
B3ZS
44.736 Mbps ± 20 ppm
450 ft. to cross-connect facility
+5.7 dBm to –7.4 dBm
–1.8 to +5.7 dBm
Bipolar, Return to Zero
75 ohms nominal
B3ZS
44.736 MHz ± 20 ppm
450 ft. to cross-connect facility
Bipolar, Return to Zero
100 ohms ± 5%
0 to –10 dB
AMI or B8ZS
Standard DS1 code at
1.544 Mbps ± 200 bps (130 ppm)
Per GR-499-CORE, Issue 4
0 dB
<35 dB @ 196 kHz
Two-pair, single or mixed gauges With or without bridged taps
Two 784 kbps full duplex pairs,
2B1Q modulation
135 ohms nominal
–132 ± 5 VDC
>20 dB
+13.5 dBm ± 0.5 dBm
REMARKS
With splitter/combiner
With splitter/combiner
Transparent to frame format
22 AWG ABAM
135 ohm termination
Balanced
40 kHz to 200 kHz
(continued)
