Installation and Wiring

■Installation

Connect valve manifold to the SI unit.
•Dimensions for installation
n
L 1
L1
L2
n
L 9
L1 232.7
L2 192
The above table shows dimensions as an example for the SY5000 series valve manifold.
Refer to the valve manifold section in the valve catalogue for valve manifold dimensions.
2 3 4
120.7 136.7 152.7
80 96 112
10 11 12
248.7 264.7 280.7
208 224 240
n: number of valve stations
5 6
168.7 184.7
128 144
13 14
296.7 312.7
256 272
-11-
7 8
200.7 216.7
160 176
15 16
328.7 344.7
288 304
(mm)
