Hardware Configuration

■EDS file and icon

The compatible EDS file is required to configure the SI unit within an EtherNet/IP
Please download the latest EDS file from the SMC website (URL https://www.smcworld.com).
: The method of installing the EDS file depends on the configuration software, so please refer to the configuration software manual.
EDS file
Product number
1 EX260-SEN2-X205

■Setting using RSLogix5000

The method of connecting the SI unit with a Rockwell Automation EtherNet/IP
below. Refer to the RSLogix5000
: The screens shown below are based on using the Rockwell Automation RSLogix5000
TM
RSLogix5000 is a trademark of Rockwell Automation.
TM
For RSLogix5000 , it is possible to perform settings without using the EDS file.
○Setting without using the EDS file
•Select the master in the [I/O Configuration] folder, and select [New Module].
File name
ex260_sen2_x205_24_v.zip
TM
TM manual for further details.
-19-
TM
Contents (EDS file and icon)
ex260_sen2_x205_24_v.eds, ex260-sen2-x205.ico
TM
(master) module is shown
TM
software.
network.
No.EX※※-OMX1001
