Installation and Wiring

■Installation

Connect valve manifold to the SI unit.
•Dimensions for installation
n
L
L1
L2
n
L
L1 232.7
L2 192
The above table shows dimensions as an example for the SY5000 series valve manifold.
Connectable valve manifolds are the same as for EX250 series SI unit.
Refer to the EX250 series valve manifold section in the valve catalogue for valve manifold dimensions.
1 2 3
120.7 136.7
80 96
9 10 11
248.7 264.7
208 224
4 5 6
152.7 168.7 184.7
112 128 144
12 13 14
280.7 296.7 312.7
240 256 272
-10-
n: number of valve stations
7 8
200.7 216.7
160 176
15 16
328.7 344.7
288 304
(mm)
