LED Indication and Settings

○LED indication
LED LED Status
OFF
Green ON
Green flashing
NS
Red flashing
Red ON
OFF
Green ON
Green flashing
MS
Red flashing
Red ON
OFF
Green ON
L/A1
Green flashing
OFF
Green ON
L/A2
Green flashing
Yellow ON
PWR(V)
OFF
The SI unit operating voltage is not supplied or the IP address is not set.
TM
EtherNet/IP communications established.
TM
EtherNet/IP communications not established.
TM
EtherNet/IP communications time out.
IP address duplicated.
The SI unit operating voltage is not supplied.
Operating normally.
Either of the following conditions are detected.
•The unit has not been configured correctly.
•The master is idle state.
Recoverable error.
Unrecoverable error.
BUS IN side: No Link, No Activity
BUS IN side: Link, No Activity
BUS IN side: Link, Activity
BUS OUT side: No Link, No Activity
BUS OUT side: Link, No Activity
BUS OUT side: Link,
Load voltage for the valve is supplied
Load voltage for the valve is not supplied or is outside the tolerance range
(19 V or less)
