Summary of Contents for SMC Networks EX140-SDN1
- Page 1 No.EX※※-OME0016-B PRODUCT NAME SI unit MODEL / Series / Product Number EX140-SDN1...
- Page 2 Table of Contents 1. Safety instructions 2. Specifications 2-1. General specifications 2-2. Electrical ant network specifications 2-3. Applicable solenoid valve series 3. Wiring and setting 3-1 Connection type 3-2 Address setting 4. LED indicator and Physical dimensions 4-1 LED indication 4-2 Physical dimensions 5.
- Page 3 1. Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
- Page 4 1. Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 Operator ♦This operation manual is intended for those who have knowledge of machinery using pneumatic equipment, and have sufficient knowledge of assembly, operation and maintenance of such equipment. Only those persons are allowed to perform assembly, operation and maintenance. ♦Read and understand this operation manual carefully before assembling, operating or providing maintenance to the product.
- Page 6 ■NOTE ○Follow the instructions given below when designing, selecting and handling the product. •The instructions on design and selection (installation, wiring, environment, adjustment, operation, maintenance, etc.) described below must also be followed. ∗Product specifications •When conformity to UL is required, the SI unit should be used with a UL1310 Class 2 power supply. •Use the specified voltage.
- Page 7 ∗Environment •Do not use the product in area that is exposed to corrosive gases, chemicals, sea water, water or steam. Otherwise failure or malfunction can result. •Do not use in an area where surges are generated. If there is equipment which generates a large amount of surge (solenoid type lifter, high frequency induction furnace, motor, etc.) close to the product, this may cause deterioration or breakage of the internal circuit of the product.
- Page 8 2. Specifications 2-1. General specifications Item Specifications Operating temperature range Operating: 0 to +50°C, Storage: -20 to +60°C (No freezing or condensation) Storage temperature range 35 to 85%RH (No condensation) Withstand voltage 1500VAC for 1 minute, between external terminals and ground Insulation resistance 500VDC 2MΩ...
- Page 9 No.EX -OME0016-B...
- Page 10 No.EX -OME0016-B...
- Page 11 Applicable cable of the power supply connector Cable cross section Single wire, stranded wire 0.2mm to 2.5mm /AWG12 to 24 CAUTION ·Before wiring, be sure to turn power supply off. · Securely tighten the set screws for cable and connector using the tightening torque of 0.5 to 0.6 [Nm].
- Page 12 -11- No.EX -OME0016-B...
- Page 13 -12- No.EX -OME0016-B...
- Page 14 -13- No.EX -OME0016-B...
- Page 15 -14- No.EX -OME0016-B...
- Page 16 Revision history A: Contents revised in several places. B: Contents revised in several places [May 2024] Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
