30 Technical information

30.3 Dimensions

30.3.1 Positioning of patient, dentist and assistant

172 Planmeca Compact i
Instrument classifications
Instrument
Luzzani Ergo 3-way syringe
Luzzani Minibright 6-way syringe
Luzzani Minibright 6-way syringe with LED
PM fibre optic turbine hose S
Bien-Air MCX brushless micromotor with LED
Planmeca Minetto brushless micromotor with LED
EMS No Pain scaler
LM-ProPower Ultra scaler
LM-ProPower UltraLED scaler
Planmeca Lumion Plus LED polymerisation light
Planmeca Somia USB intraoral camera
Planmeca Emerald intraoral scanner
The following picture shows an example of how to position the dentist and
assistant during treatment.
The patient must always be positioned in the patient chair, with arms and
legs resting on the upholstery. The dentist and assistant can move within the
areas marked in the picture below.
NOTE
The following picture is an example only and presents one possible
scenario. The actual positioning of dentist and assistant depends on the
used working method, treatment situation, region etc. and can therefore not
be explicitly stated in this manual.
Type
B
B
B
B
B
B
B
B
B
B
BF
B
