30.2 Instrument classifications

User's manual
Humidity:
Quality:
Oil contamination:
Particulate
contamination:
Connection:
Water and air filters
Water filter:
Air filter:
Replacement of water and air filters should be performed by qualified
service technician according to the maintenance schedule.
See section "Annual maintenance" on page 6.
Suction connection
Vacuum:
Flow rate:
Connection:
Type:
Class:
Drain connection
Capacity:
Connection:
Water and air quick-connectors (optional)
Output pressure:
The electrical classification of the instrument is marked on the instrument
hose either as B or BF. If there is no marking, no electricity flows through the
instrument.
Type B
Type BF
The following lists the instruments that are available for the Planmeca dental
unit and their electrical classification type.
Instrument classifications
Instrument
dew point not greater than −20 °C at atmospheric
pressure
medical grade, dry and oil-free
3
max. 0.5 mg/m
≤ 100 particles per cubic meter for 1 μm to 5 μm
particle size
1/4"
25 µm (internal), 5 µm (external suggested)
25 µm (internal)
≥ 150 mbar
≥ 550 l/ min
Ø 50 / 46 mm
Medium volume
Wet or dry depending on installed options
min. 10 l/min
Ø 50 / 46 mm
water 2.8 bar, air 5.5 bar (regulated internal water
and air pressure
30 Technical information
Type
Planmeca Compact i 171
