27 Help and error messages

27.3.6 Suction holder related error messages

156 Planmeca Compact i
Instrument multiplexer related error messages
ERROR EXPLANATION
CODE
E36.2 Spray air measurement over range.
Check if micromotor handpiece has air- and waterlines. Switch
off spray water and air if there are no air- and waterlines in
instrument or handpiece.
E36.3 Spray water measurement over range.
Check if micromotor handpiece has air- and waterlines. Switch
off spray water and air if there are no air- and waterlines in
instrument or handpiece.
E36.4 Differential pressure sensor output >5 V.
E37 Pressure sensor cable not properly attached to IMUX.
E39 Drive (cooling) air valve control servo cannot maintain
pressure to instrument.
E42 Air coolant (spray air) control servo cannot maintain required
pressure.
E45 Water coolant (spray water) control servo cannot maintain
required pressure.
Suction holder related error messages
ERROR EXPLANATION
CODE
E47 Suction holder is of new type.
E47.1 Suction holder in branch 1 is of new type.
Update MCB software.
E47.2 Suction holder in branch 2 is of new type.
Update MCB software.
E48.1 No suction holders detected.
Either the holder is missing or faulty, or the cable to the holder
is loose or faulty.
E48.2 Suction holder related error messages.
E48.3 Suction holder related error messages.
E48.4 Suction holder related error messages.
E49.1 Suction holder PCB or its cable is faulty in branch 1.
Either the holder is missing or faulty, or the cable to the holder
is loose or faulty.
E49.2 Suction holder PCB or its cable is faulty in branch 2.
Either the holder is missing or faulty, or the cable to the holder
is loose or faulty.
E50 Unidentified STCS jumper configuration.
E50.1 Water management system (WMS) must be set to Bottle
water off -mode when starting suction cleaning.
